80–95°C Indicator Material (Vacuum-Use Thermolabel / 10 sheets)
JAN
4550061855003
ASIN
B09S5VKL8Z
Maker
Model No.
EA722ZG-80
Color
Size
8×20mm
Description
▪️Manufacturer…NOF Techno Industries
▪️Model Number…VL-80
▪️Product Name…Vacuum Temperature Indicator Label
▪️Indicated Temperature…80/85/90/95°C
▪️Size…8×20mm
▪️Quantity per Pack…10 sheets
▪️Color before change…Light yellow
▪️Color after change…Black
▪️Color change accuracy…±2°C ▪️Application…Temperature control during etching, vacuum deposition, and processing steps.
▪️A label-shaped temperature control material designed for vacuum environments from 1 Pa to atmospheric pressure.
▪️Temperature at 1 Pa to atmospheric pressure is immediately visible.
▪️Color change temperature can be measured with ±2℃~4℃ accuracy even under reduced pressure conditions. ▪️ Low-outgassing materials are used to minimize outgassing from the label.
▪️ Do not alter the shape of this product, such as by cutting it. Doing so may cause color change performance to fluctuate or durability to decrease.
▪️ Use below 230°C. Use above 230°C may cause unexpected outgassing. ▪️When removing the label, allow it to cool to near room temperature (20°C) and then promptly peel it off using tweezers or similar tools. Cooling below room temperature or leaving it attached for extended periods may make removal difficult. If adhesive residue remains on the surface after removal, it can be wiped off with thinner or similar solvent.
▪️Irreversible
▪️4-point system
▪️Usable under reduced pressure (1Pa to atmospheric pressure)
▪️ Materials: Film, temperature-indicating ink, paper, adhesive
Brand Name: Esco
▪️ Manufacturer: Nippon Oil & Energy Industries
▪️ Model Number: VL-80
▪️ Product Name: Vacuum Thermolabel
▪️ Indicated Temperature: 80/85/90/95°C
▪️ Size: 8×20mm
▪️ Quantity per Pack: 10 sheets ▪️ Pre-change color: Pale yellow
▪️ Post-change color: Black
▪️ Color change accuracy: ±2℃
▪️ Applications: Temperature control during etching, vacuum deposition, and processing steps
▪️ A label-shaped temperature management material compatible with vacuum environments for use from 1Pa to atmospheric pressure.
▪️ Temperature at 1Pa to atmospheric pressure is immediately visible.
▪️ Measurement is possible under reduced pressure conditions with color change accuracy of ±2℃ to ±4℃. ▪️ Low-outgassing materials are used to minimize outgassing from the label.
▪️ Do not alter the shape of this product, such as by cutting it. Doing so may cause color change performance to fluctuate or durability to decrease.
▪️ Use below 230°C. Use above 230°C may cause unexpected outgassing. ▪️When removing the label, allow it to cool to near room temperature (20°C) and then promptly peel it off using tweezers or similar tools. Cooling below room temperature or leaving it attached for extended periods may make removal difficult. If adhesive residue remains on the surface after removal, it can be wiped off with thinner or similar solvent.
▪️Irreversible
▪️4-point system ▪️ Usable under reduced pressure (1 Pa to atmospheric pressure)
▪️ Materials: Film, temperature-indicating ink, paper, adhesive
4550061855003
80–95°C Temperature Indicator (Vacuum Thermolabel / 10 sheets)
(text created at , 2025-05-09)
▪️Model Number…VL-80
▪️Product Name…Vacuum Temperature Indicator Label
▪️Indicated Temperature…80/85/90/95°C
▪️Size…8×20mm
▪️Quantity per Pack…10 sheets
▪️Color before change…Light yellow
▪️Color after change…Black
▪️Color change accuracy…±2°C ▪️Application…Temperature control during etching, vacuum deposition, and processing steps.
▪️A label-shaped temperature control material designed for vacuum environments from 1 Pa to atmospheric pressure.
▪️Temperature at 1 Pa to atmospheric pressure is immediately visible.
▪️Color change temperature can be measured with ±2℃~4℃ accuracy even under reduced pressure conditions. ▪️ Low-outgassing materials are used to minimize outgassing from the label.
▪️ Do not alter the shape of this product, such as by cutting it. Doing so may cause color change performance to fluctuate or durability to decrease.
▪️ Use below 230°C. Use above 230°C may cause unexpected outgassing. ▪️When removing the label, allow it to cool to near room temperature (20°C) and then promptly peel it off using tweezers or similar tools. Cooling below room temperature or leaving it attached for extended periods may make removal difficult. If adhesive residue remains on the surface after removal, it can be wiped off with thinner or similar solvent.
▪️Irreversible
▪️4-point system
▪️Usable under reduced pressure (1Pa to atmospheric pressure)
▪️ Materials: Film, temperature-indicating ink, paper, adhesive
Brand Name: Esco
▪️ Manufacturer: Nippon Oil & Energy Industries
▪️ Model Number: VL-80
▪️ Product Name: Vacuum Thermolabel
▪️ Indicated Temperature: 80/85/90/95°C
▪️ Size: 8×20mm
▪️ Quantity per Pack: 10 sheets ▪️ Pre-change color: Pale yellow
▪️ Post-change color: Black
▪️ Color change accuracy: ±2℃
▪️ Applications: Temperature control during etching, vacuum deposition, and processing steps
▪️ A label-shaped temperature management material compatible with vacuum environments for use from 1Pa to atmospheric pressure.
▪️ Temperature at 1Pa to atmospheric pressure is immediately visible.
▪️ Measurement is possible under reduced pressure conditions with color change accuracy of ±2℃ to ±4℃. ▪️ Low-outgassing materials are used to minimize outgassing from the label.
▪️ Do not alter the shape of this product, such as by cutting it. Doing so may cause color change performance to fluctuate or durability to decrease.
▪️ Use below 230°C. Use above 230°C may cause unexpected outgassing. ▪️When removing the label, allow it to cool to near room temperature (20°C) and then promptly peel it off using tweezers or similar tools. Cooling below room temperature or leaving it attached for extended periods may make removal difficult. If adhesive residue remains on the surface after removal, it can be wiped off with thinner or similar solvent.
▪️Irreversible
▪️4-point system ▪️ Usable under reduced pressure (1 Pa to atmospheric pressure)
▪️ Materials: Film, temperature-indicating ink, paper, adhesive
4550061855003
80–95°C Temperature Indicator (Vacuum Thermolabel / 10 sheets)
(text created at , 2025-05-09)
Package
Size (Approx.):
Size (Approx.):
480x20x1150 mm
Package
Weight (Approx.):
Weight (Approx.):
6 g
7,037 JPY (Including Tax)
