60–75°C temperature indicator (vacuum-use thermolabel / 10 sheets)
JAN
4550061855010
ASIN
B09S5NF5TN
Maker
Model No.
EA722ZG-60
Color
Size
8×20mm
Description
Brand Name: Esco
▪️ Manufacturer: Nippon Oil & Energy Industries Co., Ltd.
▪️ Model Number: VL-60
▪️ Product Name: Vacuum Thermolabel
▪️ Display Temperature: 60/65/70/75°C
▪️ Size: 8×20mm
▪️ Quantity per Pack: 10 sheets ▪️ Pre-Discoloration Color…Light Yellow
▪️ Post-Discoloration Color…Black
▪️ Discoloration Accuracy…±2℃
▪️ Applications…Temperature control during etching, vacuum deposition, and processing steps
▪️ A label-shaped temperature management material designed for vacuum environments from 1Pa to atmospheric pressure.
▪️ Temperature at 1Pa to atmospheric pressure is immediately visible.
▪️ Measurement is possible under reduced pressure conditions with a discoloration temperature accuracy of ±2℃ to ±4℃. ▪️ Low-outgassing materials are used to minimize outgassing from the label.
▪️ Do not alter the shape of this product, such as by cutting it. Doing so may cause color change performance to fluctuate or durability to decrease.
▪️ Use below 230°C. Use above 230°C may cause unexpected outgassing. ▪️When removing the label, allow it to cool to near room temperature (20°C) and then promptly peel it off using tweezers or similar tools. Cooling below room temperature or leaving it attached for extended periods may make removal difficult. If adhesive residue remains on the surface after removal, it can be wiped off with thinner or similar solvent.
▪️Irreversible
▪️4-point system ▪️ Usable under reduced pressure (1 Pa to atmospheric pressure)
▪️ Materials: Film, temperature-indicating ink, paper, adhesive
4550061855010
60–75°C Temperature Indicator (Vacuum Thermolabel / 10 sheets)
(text created at , 2025-05-09)
▪️ Manufacturer: Nippon Oil & Energy Industries Co., Ltd.
▪️ Model Number: VL-60
▪️ Product Name: Vacuum Thermolabel
▪️ Display Temperature: 60/65/70/75°C
▪️ Size: 8×20mm
▪️ Quantity per Pack: 10 sheets ▪️ Pre-Discoloration Color…Light Yellow
▪️ Post-Discoloration Color…Black
▪️ Discoloration Accuracy…±2℃
▪️ Applications…Temperature control during etching, vacuum deposition, and processing steps
▪️ A label-shaped temperature management material designed for vacuum environments from 1Pa to atmospheric pressure.
▪️ Temperature at 1Pa to atmospheric pressure is immediately visible.
▪️ Measurement is possible under reduced pressure conditions with a discoloration temperature accuracy of ±2℃ to ±4℃. ▪️ Low-outgassing materials are used to minimize outgassing from the label.
▪️ Do not alter the shape of this product, such as by cutting it. Doing so may cause color change performance to fluctuate or durability to decrease.
▪️ Use below 230°C. Use above 230°C may cause unexpected outgassing. ▪️When removing the label, allow it to cool to near room temperature (20°C) and then promptly peel it off using tweezers or similar tools. Cooling below room temperature or leaving it attached for extended periods may make removal difficult. If adhesive residue remains on the surface after removal, it can be wiped off with thinner or similar solvent.
▪️Irreversible
▪️4-point system ▪️ Usable under reduced pressure (1 Pa to atmospheric pressure)
▪️ Materials: Film, temperature-indicating ink, paper, adhesive
4550061855010
60–75°C Temperature Indicator (Vacuum Thermolabel / 10 sheets)
(text created at , 2025-05-09)
Package
Size (Approx.):
Size (Approx.):
490x20x1140 mm
Package
Weight (Approx.):
Weight (Approx.):
6 g
