Sanwa Supply Docking Station USB Type-C Connection 4K/60Hz Dual Display Expansion Support HDMI×2/LAN×1/USB-A×2/USB-C×1 Smart PD Supported (PD 100W Input/95W Output) 50cm Cable Length with L-Shaped Adapter Included USB-DKM9S

4969887595657

B0DB81WNCK

USB-DKM8S

Sanwa Supply - USB Type-C Docking Station - USB-DKM8S
▪️A docking station equipped with Smart PD to deliver stable power to your computer.\
▪️A Type-C mobile docking station featuring HDMI×2.\
▪️Equipped with 2 HDMI ports, allowing simultaneous display expansion for two monitors.\
▪️Charge your computer via the dedicated USB PD port. ※Supports PD 100W\
▪️Includes USB 5Gbps (3.2 Gen1) and 2 USB-A ports for connecting peripherals.\
▪️Includes an L-shaped adapter.\
【 PC Connection Port 】\


■Connector Type: USB Type-C\


■Compliant Standards: USB 5Gbps (USB3.2 Gen1/3.1 Gen1/3.0) compliant\
※USB 5Gbps is the renamed USB3.2 Gen1 (USB3.1 Gen1/USB3.0) by USB-IF (USB Implementers Forum) and is the same specification.\


■Maximum USB PD Output: Approx. 100W\


■Cable Length: 20cm\


■Cable Type: Integrated Type\
【 USB Ports 】\


■Number of Ports: 2 Ports\


■Maximum Data Transfer Speed (Theoretical): 5Gbps\


■USB Type-A Female/USB 5Gbps: 2 Ports\


■Supply Current: Max 1500mA\
(Total for all ports/Bus-powered)\
※If the connected device's current draw exceeds this product's supply current, it may not operate normally via bus power.\
【 Power Supply 】\


■Power Supply Method: Bus-powered/Self-powered (when connected to power source)\


■Unit Power Consumption: 0W\


■USB PD Input Port: Yes\


■Maximum USB PD Input: 100W\
※Depending on your computer or PD power adapter, a warning may appear recommending use of the power adapter supplied with your computer. This is normal and does not affect operation.\
【 Video Output Ports 】\


■Supported Output Displays: 2\


■Connectors: HDMI Type A (19-pin) Female ×2\


■Maximum Supported Resolution: Up to 3840×2160 (4K/60Hz)\
*The listed supported resolution requires your computer to support DisplayPort Alt Mode (DP 1.4 or higher).\
*Outputting at 4K resolution requires a display capable of 4K resolution and content that supports 4K resolution.\


■Maximum Supported Resolution/Refresh Rate:\
3840×2160\


■HDCP: 2.2, 2, 1.4\


■HDMI: 2 ports\
【 LAN Port 】\


■Port Type: RJ-45 port (Auto MDI/MDI-X), Auto-Negotiation supported\
※Wake On LAN functionality is supported, but compatibility varies by PC model; operation is not guaranteed.\
※Depending on connected devices, Wi-Fi must be turned OFF to use the wired network.\


■Supported Standards: IEEE802.3 (10BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3ab (1000BASE-T)\


■ Transmission Speed (Theoretical): 1000Mbps, 100Mbps, 10Mbps\
※Regarding communication speed: 1000BASE-T is supported only when connected via USB 5Gbps (USB 3.2 Gen1).\


■ Access Method: CSMA/CD\
【 Common Specifications 】\


■ Driver: Not required\


■Dimensions: Approx. W115 × D59 × H14 mm

163x34x215 mm

160 g
