Rc 1/2 Electric Ball Valve (Vertical Type/Bronze)
JAN
4550061561331
ASIN
B08TB6YL12
Maker
Model No.
EA470BG-304
Color
Size
d:10mm d1:Rc1/2 H:109.5mm H1:33.5mm L:67mm L1:33.5mm S1:28mm H2:70mm H3:5mm D:60m
Description
Material: Body/Housing: CAC406, Cap: C3771, Stem: C6782BD + Cr plating, Disc/Ball: C3531 + Ni-Cr plating, Body Seat/Ball Seat: PTFE, O-Ring: FKM Power Supply: AC100V (50/60Hz) Screw Size (Rc): 1/2"
Opening/Closing Time: 50Hz: Approx. 12 sec 60Hz: Approx. 10 sec Rated Current: 90mA Maximum Power Consumption: 9W
Maximum Output Torque: 1.9N·m Function: 180° Forward/Reverse Rotation Protection Structure: IP56 Equivalent
Nominal Diameter (A Designation): 15 Size: d: 10mm d1: Rc1/2 H: 109.5mm H1: 33.5mm L: 67mm L1: 33.5mm S1: 28mm H2: 70mm H3: 5mm D: 60mm Maximum Operating Pressure: Water/Oil/Air (80°C or below): 1.0MPa, Water/Oil/Air (100°C or below): 0.5MPa
Fluid: Water/Oil/Air Reduced Bore Type Ball Valve
Brand Name: Esco
Material: Body/Housing: CAC406
Material: Body/Housing: CAC406, Cap: C3771, Stem: C6782BD + Cr plating, Disc/Ball: C3531 + Ni-Cr plating, Body Seat/Ball Seat: PTFE, O-Ring: FKM Power Supply: AC100V (50/60Hz) Screw Size (Rc): 1/2"
Opening/Closing Time: 50Hz: Approx. 12 sec 60Hz: Approx. 10 sec Rated Current: 90mA Maximum Power Consumption: 9W
Maximum Output Torque: 1.9N･m Function: 180° Forward/Reverse Rotation Protection Structure: IP56 Equivalent
Nominal Diameter (A Designation): 15 Size: d: 10mm d1: Rc1/2 H: 109.5mm H1: 33.5mm L: 67mm L1: 33.5mm S1: 28mm H2: 70mm H3: 5mm D: 60mm Maximum Operating Pressure: Water/Oil/Air (80°C or below): 1.0MPa, Water/Oil/Air (100°C or below): 0.5MPa
Fluid: Water/Oil/Air Reduced Bore Type Ball Valve
4550061561331\ nB08TB6YL12
Rc 1/2 Electric Ball Valve (Vertical Type/Bronze)
(text created at , 2025-11-12)
Opening/Closing Time: 50Hz: Approx. 12 sec 60Hz: Approx. 10 sec Rated Current: 90mA Maximum Power Consumption: 9W
Maximum Output Torque: 1.9N·m Function: 180° Forward/Reverse Rotation Protection Structure: IP56 Equivalent
Nominal Diameter (A Designation): 15 Size: d: 10mm d1: Rc1/2 H: 109.5mm H1: 33.5mm L: 67mm L1: 33.5mm S1: 28mm H2: 70mm H3: 5mm D: 60mm Maximum Operating Pressure: Water/Oil/Air (80°C or below): 1.0MPa, Water/Oil/Air (100°C or below): 0.5MPa
Fluid: Water/Oil/Air Reduced Bore Type Ball Valve
Brand Name: Esco
Material: Body/Housing: CAC406
Material: Body/Housing: CAC406, Cap: C3771, Stem: C6782BD + Cr plating, Disc/Ball: C3531 + Ni-Cr plating, Body Seat/Ball Seat: PTFE, O-Ring: FKM Power Supply: AC100V (50/60Hz) Screw Size (Rc): 1/2"
Opening/Closing Time: 50Hz: Approx. 12 sec 60Hz: Approx. 10 sec Rated Current: 90mA Maximum Power Consumption: 9W
Maximum Output Torque: 1.9N･m Function: 180° Forward/Reverse Rotation Protection Structure: IP56 Equivalent
Nominal Diameter (A Designation): 15 Size: d: 10mm d1: Rc1/2 H: 109.5mm H1: 33.5mm L: 67mm L1: 33.5mm S1: 28mm H2: 70mm H3: 5mm D: 60mm Maximum Operating Pressure: Water/Oil/Air (80°C or below): 1.0MPa, Water/Oil/Air (100°C or below): 0.5MPa
Fluid: Water/Oil/Air Reduced Bore Type Ball Valve
4550061561331\ nB08TB6YL12
Rc 1/2 Electric Ball Valve (Vertical Type/Bronze)
(text created at , 2025-11-12)
Package
Size (Approx.):
Size (Approx.):
172x115x232 mm
Package
Weight (Approx.):
Weight (Approx.):
1006 g
33,631 JPY (Including Tax)
Stock :
2
Scheduled Shipping:
2026-07-14
Quantity :
