Sanwa Supply 8K-Compatible HDMI Switch (2 Inputs, 1 Output) SW-HDR8K21L

4969887595411

B0C9CZX29D

SW-HDR8K21L

Sanwa Supply SW-HDR8K21L 8K HDMI Switch (2 Inputs, 1 Output) This HDMI switch allows you to easily switch the video and audio from two HDMI devices to a single 8K display. Supports resolutions up to 8K/60Hz and 4K/120Hz, delivering beautiful, high-definition HDMI signal output. Supports high-brightness HDR (High Dynamic Range) and HDCP 2.3. Supports 4K/120Hz output for PlayStation 5®. Compatible with Nintendo Switch™ and PlayStation 4 Pro®. Two-way switching: "Automatic Switching" automatically switches ports when the HDMI device is turned on, and "Fully Manual Switching" prevents accidental switching with a single button press. All HDMI terminals are gold-plated for rust resistance and signal degradation. Supports Dolby True HD and DTS HD Master Audio. Note: *PlayStation, PLAYSTATION, PS4, and PS5 are registered trademarks of Sony Interactive Entertainment Inc. *Nintendo Switch is a trademark or registered trademark of Nintendo. *Operation is not guaranteed with all HDMI devices. *When connecting at 8K/60Hz, 8K/30Hz, or 4K/120Hz, an Ultra HDMI 2.1 cable is required. *To output at 4K/120Hz, 120Hz-compatible game software, cables, input devices, and output devices are required. *To play 4K/HDR video, all equipment, cables, and software must be 4K/HDR compatible. *We recommend connecting and using a USB power cable for stable operation. *This product is bus-powered, meaning it runs on power from the HDMI device. However, you may experience symptoms such as the screen temporarily going dark or the video cutting out when starting up the device. In this case, connecting a USB power cable to provide a stable power supply to the product may resolve the issue. 【About the screen display time when switching】 *When switching ports, it usually takes about 3 to 5 seconds for the image to appear. This is not a symptom of this product, but the time it takes for the HDMI device (such as a recorder) to recognize the display and begin video output, and is dependent on the performance of the HDMI device. This product itself completes the port switch the moment you press the switch button.

■Maximum resolution: 8K/60Hz

■Main supported resolutions: 7680×4320 (60Hz, 4:4:4), 7680×4320 (60Hz, 4:2:0), 7680×4320 (30Hz, 4:4:4) 3840×2160 (120Hz, 4:4:4), 3840×2160 (60Hz, 4:4:4) 1920×1080p (24/25/30/50/60/120Hz/240Hz) 1920×1080i (50/60Hz) 1280×720p (50/60Hz) 720×576p (50Hz) 720×480p (60Hz) *Depends on the resolution of the connected TV or monitor.

■Interface: Input: 2 x HDMI Type A (19-pin) female connectors. Output: 1 x HDMI Type A (19-pin) female connector. Power supply: 1 x microUSB female connector. HDMI standard: HDMI Ver. 2.1. HDCP: HDCP 1.4, HDCP 2.2, HDCP 2.3. Switching: 2 HDMI inputs, 1 HDMI output. Switching method: Main unit switching button. *Automatic switching function for powered-on devices. Data rate: 48 Gbps. Device-to-device control (CEC): Supported. *Operation is not guaranteed with all devices. Power Consumption: 1.75W (Max.) Dimensions: W120.3 x D45.1 x H15mm Weight: Approx. 52g Pixel Clock (Max.): 1200MHz Supported Audio Formats: LPCM 2/5.1/7.1ch, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS Input DDC Signal: 5V Environmental Requirements: Operating Temperature: 0-50°C, Humidity: 0-80% (No condensation) Storage Temperature: -20-60°C, Humidity: 5-90% (No condensation) HDR: Supported Signal Classification: HDMI Number of Circuits: 2 x 1 Package Contents: microUSB cable (for power supply), instruction manual, warranty card Brand Name: Sanwa Supply Material: ABS This HDMI switch allows you to easily switch between video and audio from two HDMI devices and output them to a single 8K display. It supports resolutions up to 8K/60Hz and 4K/120Hz, delivering beautiful, high-definition HDMI signals. It supports high-brightness HDR (High Dynamic Range) and HDCP 2.3. It supports 4K/120Hz output for PlayStation 5®. It has also been tested with Nintendo Switch™ and PlayStation 4 Pro®. Product code: 4969887595411. Sanwa Supply 8K HDMI Switch (2 Inputs, 1 Output) SW-HDR8K21L (text created at , 2025-05-12)

120x43x238 mm

130 g
