Sanwa Supply USB Type-C Docking Station USB-DKM11S

4969887783832

B0FB921DXD

USB-DKM11S

Sanwa Supply - USB Type-C Docking Station - USB-DKM11S
▪️This Type-C mobile docking station enables expansion connections to HDMI displays, USB devices, and wired LAN using just one Type-C cable.\

▪️Supports MAC address pass-through functionality.\
※Compatible only with computers supporting MAC address pass-through.\
▪️Connect with a single Type-C cable to comfortably operate a large display and USB devices. When traveling or attending meetings, simply disconnect the Type-C cable for quick portability.\
▪️ Supports HDMI display expansion via USB Type-C using “DisplayPort Alternate Mode” without requiring software installation, enabling easy setup of multi-display environments (Mirror Mode/Extended Mode).\
▪️ Supports 4K/30Hz HDR, outputting beautiful, high-definition HDMI signals.\
▪️ Supports “USB Power Delivery (USB PD)” via USB Type-C, enabling power delivery to connected computers through this product. Supports charging up to 100W.\
▪️Supports Gigabit Ethernet, enabling Gigabit network connectivity and wired LAN connection via a single Type-C cable.\
※Supports Wake On LAN functionality, but operation is not guaranteed as compatibility varies by computer model.\
【 PC Connection Port 】\


■Connector Type: USB Type-C\


■Compliant Standards: USB 5Gbps (USB3.2 Gen1/3.1 Gen1/3.0) compliant\
※USB 5Gbps is the renamed USB3.2 Gen1 (USB3.1 Gen1/USB3.0) by USB-IF (USB Implementers Forum) and is the same specification.\


■Maximum USB PD Output: 85W\


■Cable Length: 15cm\


■Cable Type: Integrated Cable\
【 USB Ports 】\


■Number of Ports: 3 Ports\


■Maximum Data Transfer Speed (Theoretical): 5Gbps\


■USB A Female/USB 5Gbps: 3 Ports\


■Supply Current: Max 3000mA (Total for all ports / Bus-powered mode)\
※If the connected device's current draw exceeds this product's supply current, it may not operate normally in bus-powered mode.\
※In self-powered mode, 1500mA can be supplied from one designated USB A port.\
【 Power Supply 】\


■Power Supply Method: Bus-powered / Self-powered (when connected to power source)\


■Unit Power Consumption: 15W\


■USB PD Input Port: Yes\


■USB PD Maximum Input: 100W\
※Depending on your computer or PD power adapter, a warning may appear recommending use of the power adapter supplied with your computer. This is normal and does not affect operation.\
【 Video Output Port 】\


■Supported Output Displays: 1\


■Maximum Supported Resolution: 4K/30Hz\
※The listed supported resolution requires your computer to support DisplayPort Alt Mode (DP 1.4 or higher).\
※Outputting at 8K resolution requires a display that supports 8K resolution and content that is also 8K resolution compatible.\


■Maximum supported resolution/refresh rate: 3840×2160\


■HDR support: Supported\


■HDCP: 2.3, 2.2, 2, 1

81x24x210 mm

120 g
