Sanwa Supply USB Type-C Docking Station HDMI/VGA Dual-Screen Output Support Black USB-CVDK19

4969887783979

B0F2HLTPVV

USB-CVDK19

Sanwa Supply - USB Type-C Docking Station (HDMI/VGA Dual Display Output Support) - USB-CVDK19
▪️ This compact USB Type-C docking station features HDMI and VGA video output ports, enabling video output to up to two displays using a single USB Type-C cable.
▪️ Equipped with a VGA video port, it supports video output to displays lacking an HDMI port.
▪️ When outputting to one display via HDMI, it supports resolutions up to 4K (3840×2160).\
※ When connecting two displays, the maximum supported resolution is HDMI: 4K (3840×2160) + VGA: Full HD (1920×1080).\

▪️Beyond video output, it also supports expanded connections for various USB devices and wired LAN.\
▪️It supports input up to 20V/5A (100W) per the USB Power Delivery (USB PD) specification. By connecting a separate USB PD-compliant AC adapter, this product can simultaneously output video, transmit data, and power a connected laptop.\
▪️ At home or in the office, connect with a single Type-C cable to comfortably operate a large display and USB devices. When traveling or attending meetings, simply disconnect the single Type-C cable for quick portability.\
▪️ Supports DisplayPort Alternate Mode for display expansion via USB Type-C connection, enabling easy use without software installation.\
▪️ Supports Gigabit Ethernet (1000BASE-T), enabling Gigabit network connectivity and wired LAN via a single USB Type-C cable.\
▪️ Compact size minimizes bulk, allowing space-saving placement on your desk. 【Important Notes】\
*Compatible with computers equipped with a USB Type-C port supporting DisplayPort Alternate Mode (DP1.4 or higher).\
*macOS does not support extended mode for two external displays.\
*Operation is not guaranteed with all devices.\
【 PC Connection Port 】\


■Connector Type: USB Type-C\


■Compliant Standard: USB 5Gbps (USB3.2 Gen1/3.1 Gen1/3.0)\
※USB 5Gbps is the renamed USB3.2 Gen1 (USB3.1 Gen1/USB3.0) by USB-IF (USB Implementers Forum) and is the same specification.\


■Maximum USB PD Output: 82W\


■Cable Length: 100cm\


■Cable Type: Detachable\
【 USB Ports 】\


■Number of Ports: 4 ports\


■Maximum Data Transfer Speed (Theoretical): 5Gbps\


■USB Type-C Female/USB 5Gbps: 1 port\


■USB A Female/USB 5Gbps: 2 ports\


■USB A Female/USB 2.0: 1 port\


■Supply Current: USB Type-C Connector (5Gbps)/Max 900mA\
USB A Connector (5Gbps)/Max 900mA per port\
USB A Connector (USB 2.0)/Max 500mA\
【 Power Supply 】\


■Power Supply Method: Bus-powered/Self-powered (when connected to power source)\


■Unit Power Consumption: 18W\


■USB PD Input Port: Yes

136x35x180 mm

236 g
